VAD1G66B On/Off Double Pole w/ 2 Lamps. 6 Terminal
PNL-BW180VT-stg
Specifications:
- Manufacturers Part# VAD1G66B-00000-000
- Function:Latching ON/OFF Double Pole
- Lamp:2 Lamps
- This is a Switch Body Only. Actuators are sold separately
- ON/OFF DP configuration
- Used by Monterey Boats, Boston Whaler and used with our custom Contura 5 engraved actuators. Typically used to control 2 independent circuits with one switch like dual blowers, dual bilge pumps, dual horns, etc.
- 12V dual lamps. The lamp in the #1 (top) position is independent, The lamp in the #2 (bottom) position is dependent and illuminates when the switch is actuated to the ON position.
- An independent lamp has both a positive and negative terminal as opposed to a dependent lamp that just has a negative terminal. Independent lamps can be lit independently of the handle position as opposed to standard "dependent" lamps that get their power internally when the handle moves to the "on" position
- 6 terminal: Terminal #8 is the power for the independent lamp (top lamp). Terminal #7 is the ground for both lamps. Terminal #2 and #5 are power in and Terminal #3 and #6 are power out. Terminal #2 and #5 operate one circuit and Terminal #3 and #6 operate the 2nd circuit. They are isolated from each other.
- Typically the independent lamp is wired to the navigation light or dash light circuit so that the lamp will always be illuminated at night when the rest of the lights are on. The engraving in certain actuators like our C5's will illuminate. The bottom lamp will illuminate when the switch is moved to the "ON" position.
- Common for Marine, RV, automotive, and other 12V DC applications.
Product Overview
VAD1G66B On/Off Double Pole w/ 2 Lamps. 6 Terminal is a practical pick for service work when you want control you can count on. It is commonly used for indicator and control circuits. This is a latest option for customers refreshing an older setup. It is a professional marine replacement part. It is built to be durable and finished to a high quality standard. If you want help confirming fitment or wiring, our customer service is responsive. You will speak with easy to work with real people with real hands on expertise.
Specifications and Details
Web Listing Details
Specifications:
- Manufacturers Part# VAD1G66B-00000-000
- Function:Latching ON/OFF Double Pole
- Lamp:2 Lamps
- This is a Switch Body Only. Actuators are sold separately
- ON/OFF DP configuration
- Used by Monterey Boats, Boston Whaler and used with our custom Contura 5 engraved actuators. Typically used to control 2 independent circuits with one switch like dual blowers, dual bilge pumps, dual horns, etc.
- 12V dual lamps. The lamp in the #1 (top) position is independent, The lamp in the #2 (bottom) position is dependent and illuminates when the switch is actuated to the ON position.
- An independent lamp has both a positive and negative terminal as opposed to a dependent lamp that just has a negative terminal. Independent lamps can be lit independently of the handle position as opposed to standard "dependent" lamps that get their power internally when the handle moves to the "on" position
- 6 terminal: Terminal #8 is the power for the independent lamp (top lamp). Terminal #7 is the ground for both lamps. Terminal #2 and #5 are power in and Terminal #3 and #6 are power out. Terminal #2 and #5 operate one circuit and Terminal #3 and #6 operate the 2nd circuit. They are isolated from each other.
- Typically the independent lamp is wired to the navigation light or dash light circuit so that the lamp will always be illuminated at night when the rest of the lights are on. The engraving in certain actuators like our C5's will illuminate. The bottom lamp will illuminate when the switch is moved to the "ON" position.
- Common for Marine, RV, automotive, and other 12V DC applications.
Fitment and Ordering Support
Customers use VAD1G66B On/Off Double Pole w/ 2 Lamps. 6 Terminal for indicator and control circuits in many marine setups. It is typically selected when you need a dependable replacement that performs well in marine conditions and delivers a high quality result. Before ordering, confirm the switch function and terminals, then compare photos and specifications to what is installed now. If anything is unclear, our support team is helpful. You will reach easy to work with real people with real hands on expertise who can help confirm the right part.
