VEBB-1 Carling ON/ON/ON rocker switch, special circuit w/24 volt lamps
PNL-BW180VT-stg
Electrical Switch for Sea Ray and Other Boats
OEM-quality marine electrical switch engineered for reliable boat system control. For Sea Ray, Boston Whaler, Grady White, and other cruisers.
Product Specifications
Type: Electrical Switch
Configuration: Switch - Standard
Application: boat electrical switching and control
SKU: ELC-009065
Details: Carlingswitch ON/ON/ON double pole V series Contura rocker switch body. This is a Switch Body Only. Actuators are sold separately. ON/ON/ON configuration. 10 terminal; special circuit ON/ON/ON - Terminals #7,#9 are Ground for the Lamps and Terminals #8,#10 are Power in for the lamps. Terminals #2,#5 are power in. Terminals #3,#6 are Power out when the actuator is in the up position. Terminals #3,#4 are Power out when the actuator is in the middle position. Terminals #1,#4 are Power out when the actuator is in the down position. Independent green 24 volt LED lamp in position 1 - wired to terminal #7 and #8 Independent Amber 24 volt LED lamp in position 2 - wired to terminal #9 and #10 Independent lamps are illuminated independently of actuator position. Independent lamps have both a negative (ground) terminal and a positive terminal that must be wired externally to illuminate. If you want an independent lamp to illuminate when the actuator is in a particular position, you have to run a jumper wire from a terminal activated by the actuator position (like #1,3,4, or 6) to a power terminal for one of the lamps (like #8 or 10) ....watch the videos!! Choose from a variety of actuators. Actuator part numbers begin with VV.
Why OEM Electrical Switches Matter
OEM electrical switches are engineered for your boat's voltage and amperage specifications. They deliver reliable operation, proper electrical protection, and long-term durability in marine environments. Using correct switches prevents electrical system failures, fires, and equipment damage.
Quality electrical components ensure system safety and reliability. Always use OEM switches rated for your boat's electrical system specifications.
Quick FAQs
Will this switch fit my boat?
Designed for Sea Ray and other standard boats. Electrical switches must match your boat's voltage and amperage specifications. Verify compatibility before ordering. Contact [email protected] with your boat model and electrical system details.
What's the difference between Single Pole and Double Pole?
Single Pole switches control one circuit. Double Pole switches control two independent circuits simultaneously. Choose based on your boat's electrical configuration. Contact [email protected] if unsure which type you need.
What's the difference between Momentary and Locking?
Momentary switches activate only while pressed. Locking (or toggle) switches stay in position until toggled again. Choose based on your application. Wrong type can cause electrical system issues.
Can I use any electrical switch?
No. Electrical switches must match your boat's voltage (12V, 24V, etc.) and amperage rating exactly. Using wrong switches risks electrical fires and system failure. Always use OEM switches rated for your specific boat system. Never substitute with automotive or general-purpose switches.
Do you have switches for older boat models?
Yes. We stock electrical switches for boats from 1980s-current production. Contact [email protected] with your boat's model year and electrical system specifications.
